Automatic tape dispenser ZCUT-9GR

Home Products Tape dispensers Automatic tape dispenser ZCUT-9GR
Automatic tape dispenser ZCUT-9GRAutomatic tape dispenser ZCUT-9GRAutomatic tape dispenser ZCUT-9GRAutomatic tape dispenser ZCUT-9GR

Automatic tape dispenser ZCUT-9GR

  • Product Item:ZCUT-9GR
  • The Min cutting length is 5mm.
  • Apply for adhesive tape and non-adhesive protect film.
  • Two rollers can be cut together.
  • Memory function/ set the OK length/ shutdown then start the machine/ still keep the original data.
  • Category:Tape dispensers
  • Inquiry

    Description

    Features:

    Anti-cutting finger safety features and design

    · Programmable 6 different length, preset and cycle counting functions (eg 50-60- 70-80-90-100mm, repeatable cycle)

    Can set the number of cutting tape to decrease,

    Can accommodate any size of the inner diameter of the tape and the maximum diameter 300 mm tape,

    Can be disassembled without the use of tools, easy to maintain and easy to repair

    Dual sensors, can cut 2 rolls of tape at a time

    Built-in tweezers, oil and easy to use partition.

    Can be cut adhesive tape: acetate cloth tape, glass fiber tape, double-sided tape, polyimide film, electrical insulation materials. Can also be cut non-adhesive materials: protective film, aluminum / copper foil, tubes, plastic tape, magic tape, ribbon and so on.


    Technical Parameters:

    Cut length: 5 - 999 mm
    Cutting width: 6 - 60 mm
    Tape thickness: 0.05 - 0.3 mm
    Transmission speed: 220mm / second About 50 sheets / minute
    Maximum outer diameter: 300 mm
    Body material: anti-static abs resin
    Rated power: ac100v-240v 50 / 60hz 25w 2a (built-in ac plug)
    Body size: 116 mm (w) x140 mm (l) x213 mm (h)
    Body weight: 1.6kg
    Accessories: power cord, lubricant, divider
    Tape: Can be cut adhesive tape: acetate cloth tape, glass fiber tape, double-sided tape, polyimide film, electrical insulation materials
